Model No. | d (mm) | D (mm) | B (mm) | C (KN) | Co (KN) | Mass(KG) |
RE15013 | 150 | 180 | 13 | 27 | 53.5 | 0.68 |
The Brief Description of Cross Roller Bearings:
Their rollers between the inner ring and the outer ring, the interval to intersect at right angles to each other are arranged. They can withstand the load from all directions (eg axial thrust load or momentum, etc.). Because the surface of the roller and the track into a linear contact and therefore, the bearing load and by the possibility of elastic deformation is small. This type of bearings are widely used in industrial automation, such as robots, machine tools and medical facilities, and need high rigidity, high speed close and still ensure accurate the occasion.
Bearing features:
1. High precision: precision at P4, P2.
2. High rigidity: this series bearings are with preload.
3. High load capacity: this series bearings can support axial load, radial load, and tilting load.
4. Small volume: this series bearings can save space for the machine.
Cross Bearing Advantages:
1. with excellent rotational accuracy
2. Installing simplifies operation
3. Bear large axial and radial loads
4.Significant savings in installation space
5. High speed capability
6. Shaft length and reduce processing costs, the geometry of thermal expansion is limited to changes .
7. Nylon spacer, low inertia, low starting torque, easy to control angle indexing
8. Optimization of preload, rigidity, high precision guide rollers running
9. Carburizing steel provides excellent impact resistance and surface abrasion resistance
10. Simple but adequate lubrication
MONTON is the only one specialized in mass production in China, and has some spot products, such as large, medium and small high-precision thin-walled roller bearings, large, medium and small high-precision cross-section thin-walled ball bearings, as well as other research and development bearing manufacturing enterprises for precision bearings in industrial robots and aerospace fields.
MONTON is a professional manufacturer of thin-walled cross roller bearings. The precision can be divided into P5, P4, P2 and USP. Our thin-walled cross roller bearings have been fully recognized and accepted by the German and Japanese markets after more than five years of verification. Welcome new and old users to call, or direct to the factory to discuss. SX011820; SX011824; SX011828; SX011832; SX011836; SX011840; SX011848; SX011860; SX011868; SX011880; SX0118/500 RB3010, RB3510, RB7013, RB9016, RB12015, RB14025, RB16025, RB18025, RB20030, RB24025, RB25025, RB25030, RB30040, RB40040, RB50040, RB50025, RB70045, RB90070, RB1000110, RB1250110 XU series and RE series, RA series, series of RU, XSA series, XSI series, XSU serieswith an inner diameter of 20mm to 3500mm.
