B71821AC/P4DBB SKF Single Row Angular Contact Ball Bearing Spindle Bearing

1
MOQ
USD
Price
B71821AC/P4DBB SKF Single Row Angular Contact Ball Bearing Spindle Bearing
Features Gallery Product Description Request A Quote
Features
Specifications
High Light:

angular contact thrust bearing

,

thin section angular contact bearings

Basic Infomation
Place of Origin: CHINA
Brand Name: MONTON
Certification: ISO9001
Model Number: B71821AC/P4DBB
Payment & Shipping Terms
Packaging Details: Singlebox
Delivery Time: 7-35 days
Payment Terms: T/T
Supply Ability: 10000PCS/WEEK
Product Description

Super Precision Angular Contact Ball Bearing Single Row Spindle Bearing B71821



Description & Applicaitons

1) Machine tools and other precision applications require superior bearing performance. Extended speed capability, a high degree of running accuracy, high system rigidity, low heat generation, as well as low noise and vibration levels are just some of the challenges.


2) Rolling bearings for general industrial applications can only partly fulfill these requirements. Therefore, We manufacture a comprehensive assortment of super-precision bearings. Theses super-precision bearings help original equipment manufacturers and end users to further optimize performance parameters of their equipment and applications.
3) The benefits differ depending on the bearing series and applications but include high speed and load carrying ability, long bearing service life, long maintenance intervals and low energy consumption.
Typical applications for super-precision bearings are:
  • metal cutting and woodworking machinery spindles
  • other machine spindles (e.g. balancing machines)
  • high speed rolling mills
  • printing machinery
  • precision ball screws
  • live centres
  • high speed turbochargers
  • vacuum pumps
  • racing cars
  • boat gyrostabilizers
  • machine components for the semiconductor industry

Features:

  • superior bearing performance
  • extended speed capability
  • high degree of running accuracy
  • high system rigidity
  • low heat generation
  • low noise and vibration levels


Specifications:


high precision contact ball bearing B71821
Model Number B71821
Structure Angular Contact
Type Ball
Brand Name MOnton
Bore Size 105mm
Outside Diameter 130mm
Thickness 13mm
Net weight 0.4kg
Seals Type Z, ZZ, RS, 2RZ, 2RS
Number of Row Single Row
Place of Origin Janpan
Material Chrome steel, Stainless steel
Cage Brass, Steel, Nylon
Vibration Level V1, V2, V3
Clearance C0, C1, C2, C3, C4, C5 etc.
Precision Rating P0, P6, P5, P4, P2
Hardness 59-63HRC
Service OEM or original brand
Sample available Yes
Manufacturer Yes
Quality guaranteed Yes
Certificate ISO9001:2008, ISO/TS16949
Application/Function Automotive, truck, tractors, construction machinery
Other Service Design service, Buyer label service
Packaging Details Industrial Packing, Individual Boxed Packing, or OEM
Delivery Detail 2-7 days after receiving the payments or deposit


Competitive Advantage:



1. Quality level: reach the same level as the Japanese and European bearings

2. Tolerance level: ABEC-1 (P0), ABEC-3 (P6)

3. Less coefficient of friction

4. High limiting speed

5. Large size range

6. variations of structure



Related Model:

Model # d D w Cr Cor
  (mm) (mm) (mm) (kN) (kN) (r/min) (r/min) (kg)
S7195J 5 13 4 0.45 0.42 32000 43000 0.0023
S7196J 6 15 5 1.1 0.92 30000 40000 0.0039
71952Q4/YA 260 360 46 12.9
71900CTA 10 22 6 14.7
71901CTA 12 24 6 14.7
71902CTA 15 28 7 0.016
71903CTA 17 30 7 0.017
71904CTA 20 37 9 0.035
71905CTA 25 42 9 0.035
71906CTA 30 47 9 0.047
71907CTA 35 55 10 0.075
71908CTA 40 62 12 0.111
71909CTA 45 68 12 0.126
71910CTA 50 72 12 0.129
71911CTA 55 80 13 0.174
71912CTA 60 85 13 0.187
71913CTA 65 90 13 0.2
71914CTA 70 100 16 0.34
71915CTA 75 105 16 0.36
71916CTA 80 110 16 0.38
71917CTA 85 120 16 0.53
71918CTA 90 125 18 0.56
71919CTA 95 130 18 0.582
71920CTA 100 140 20 0.79
71922CTA 110 150 20 0.821
71924CTA 120 165 22 0.821
71926CTA 130 180 24 1.52
71928CTA 140 190 24 1.61
71930CTA 150 210 28 1.61
71932CTA 160 220 28 2.59
71934CTA 170 230 28 2.77
71936CTA 180 250 33 4.2
71938CTA 190 260 33 6.02
71940CTA 200 280 38 6.02
71900AC 10 22 6 - - - - -
71900C 10 22 6 3 1.5 52000 69000 0.008
71900C/DB 10 22 12 - - - - -
71900C/DF 10 22 12 4.9 3.05 42000 55000 0.016
71900C/DT 10 22 12 4.9 3.05 42000 55000 0.016
71901AC 12 24 6 - - - - -
71901C 12 24 6 - - - - -
71901C/DB 12 24 12 5.15 3.45 37000 49000 0.02
71901C/DF 12 24 12 5.15 3.45 37000 49000 0.02
71901C/DT 12 24 12 5.15 3.45 37000 49000 0.02
71902AC 15 28 7 - - - - -
71902C 15 28 7 4.75 2.65 39000 52000 0.015
