71800ACP4DB High Precision Single Row Angular Contact Ball Bearing
single row angular contact ball bearings manufacturer
7900 Series Extra Light Duty Super Precision Angular Contact Ball Bearings
Super Precision Angular Contact bearings are designed for rigid, high speed, high tolerance applications. Spindle bearings used in pairs in a 'back to back' or 'face to face' arrangemet can support axial forces on both directions and moments. Bearings in a tandem arrangement can only support axial loads in one direction. Spindle bearings are available with a 15 degree or 25 degreee contact angle. Various cage options are available as well as the use of ceramic balls which allow for higher speed, lower friction and heat generation and a longer operating life. Available bore dimension range 10mm to 240mm. Super Precision also available in Radial Ball Bearings.
Super precision contact bearing series- 7900, 7000, 7200, 7300 CTDULP4
7000 Series Light Duty Super Precision Angular Contact Ball Bearings
Super Precision Angular Contact bearings are designed for rigid, high speed, high tolerance applications. Spindle bearings used in pairs in a 'back to back' or 'face to face' arrangemet can support axial forces on both directions and moments. Bearings in a tandem arrangement can only support axial loads in one direction. Spindle bearings are available with a 15 degree or 25 degreee contact angle. Various cage options are available as well as the use of ceramic balls which allow for higher speed, lower friction and heat generation and a longer operating life. Available bore dimension range 10mm to 240mm. Super Precision also available in Radial Ball Bearings.
Super precision contact bearing series- 7900, 7000, 7200, 7300 CTDULP4
7200 Series Medium Duty Super Precision Angular Contact Ball Bearings
Super Precision Angular Contact bearings are designed for rigid, high speed, high tolerance applications. Spindle bearings used in pairs in a 'back to back' or 'face to face' arrangemet can support axial forces on both directions and moments. Bearings in a tandem arrangement can only support axial loads in one direction. Spindle bearings are available with a 15 degree or 25 degreee contact angle. Various cage options are available as well as the use of ceramic balls which allow for higher speed, lower friction and heat generation and a longer operating life. Available bore dimension range 10mm to 240mm. Super Precision also available in Radial Ball Bearings.
Super precision contact bearing series- 7900, 7000, 7200, 7300 CTDULP4
7300 Series Heavy Duty Super Precision Angular Contact Ball Bearings
Super Precision Angular Contact bearings are designed for rigid, high speed, high tolerance applications. Spindle bearings used in pairs in a 'back to back' or 'face to face' arrangemet can support axial forces on both directions and moments. Bearings in a tandem arrangement can only support axial loads in one direction. Spindle bearings are available with a 15 degree or 25 degreee contact angle. Various cage options are available as well as the use of ceramic balls which allow for higher speed, lower friction and heat generation and a longer operating life. Available bore dimension range 10mm to 240mm. Super Precision also available in Radial Ball Bearings.
Part of the bearing specification :
| dimensions | item 1 | item 2 | ||
| d | D | B | ||
| 8 | 22 | 7 | 708C.T.P4A | B708C.T.P4S |
| 8 | 22 | 7 | 708AC.T.P4A | B708E.T.P4S |
| 9 | 24 | 7 | 709C.T.P4A | B709C.T.P4S |
| 9 | 24 | 7 | 709AC.T.P4A | B709E.T.P4S |
| 10 | 19 | 5 | 71800C.T.P4A | B71800C.T.P4S |
| 10 | 19 | 5 | 71800AC.T.P4A | B71800E.T.P4S |
| 10 | 22 | 6 | 71900C.T.P4A | B71900C.T.P4S |
| 10 | 22 | 6 | 71900AC.T.P4A | B71900E.T.P4S |
| 10 | 26 | 8 | 7000C.T.P4A | B7000C.T.P4S |
| 10 | 26 | 8 | 7000AC.T.P4A | B7000E.T.P4S |
| 10 | 30 | 9 | 7200C.T.P4A | B7200C.T.P4S |
| 10 | 30 | 9 | 7200AC.T.P4A | B7200E.T.P4S |
| 12 | 21 | 5 | 71801C.T.P4A | B71801C.T.P4S |
| 12 | 21 | 5 | 71801AC.T.P4A | B71801E.T.P4S |
| 12 | 24 | 6 | 71901C.T.P4A | B71901C.T.P4S |
| 12 | 24 | 6 | 71901AC.T.P4A | B71901E.T.P4S |
| 12 | 28 | 8 | 7001C.T.P4A | B7001C.T.P4S |
| 12 | 28 | 8 | 7001AC.T.P4A | B7001E.T.P4S |
| 12 | 32 | 10 | 7201C.T.P4A | B7201C.T.P4S |
| 12 | 32 | 10 | 7201AC.T.P4A | B7201E.T.P4S |
| 15 | 24 | 5 | 71802C.T.P4A | B71802C.T.P4S |
| 15 | 24 | 5 | 71802AC.T.P4A | B71802E.T.P4S |
| 15 | 28 | 7 | 71902C.T.P4A | B71902C.T.P4S |
| 15 | 28 | 7 | 71902AC.T.P4A | B71902E.T.P4S |
| 15 | 32 | 9 | 7002C.T.P4A | B7002C.T.P4S |
| 15 | 32 | 9 | 7002AC.T.P4A | B7002E.T.P4S |
| 15 | 35 | 11 | 7202C.T.P4A | B7202C.T.P4S |
| 15 | 35 | 11 | 7202AC.T.P4A | B7202E.T.P4S |
| 17 | 26 | 5 | 71803C.T.P4A | B71803C.T.P4S |
| 17 | 26 | 5 | 71803AC.T.P4A | B71803E.T.P4S |
| 17 | 30 | 7 | 71903C.T.P4A | B71903C.T.P4S |
| 17 | 30 | 7 | 71903AC.T.P4A | B71903E.T.P4S |
| 17 | 35 | 10 | 7003C.T.P4A | B7003C.T.P4S |
| 17 | 35 | 10 | 7003AC.T.P4A | B7003E.T.P4S |
| 17 | 40 | 12 | 7203C.T.P4A | B7203C.T.P4S |
| 17 | 40 | 12 | 7203AC.T.P4A | B7203E.T.P4S |
| 20 | 32 | 7 | 71804C.T.P4A | B71804C.T.P4S |
| 20 | 32 | 7 | 71804AC.T.P4A | B71804E.T.P4S |
| 20 | 37 | 9 | 71904C.T.P4A | B71904C.T.P4S |
| 20 | 37 | 9 | 71904AC.T.P4A | B71904E.T.P4S |
| 20 | 42 | 12 | 7004C.T.P4A | B7004C.T.P4S |
| 20 | 42 | 12 | 7004AC.T.P4A | B7004E.T.P4S |
| 20 | 47 | 14 | 7204C.T.P4A | B7204C.T.P4S |
| 20 | 47 | 14 | 7204AC.T.P4A | B7204E.T.P4S |
| 25 | 37 | 7 | 71805C.T.P4A | B71805C.T.P4S |
| 25 | 37 | 7 | 71805AC.T.P4A | B71805E.T.P4S |
| 25 | 42 | 9 | 71905C.T.P4A | B71905C.T.P4S |
| 25 | 42 | 9 | 71905AC.T.P4A | B71905E.T.P4S |
Angular contact ball bearing:
Angular contact ball bearings are particularly suitable for carrying combined (axial and radial) loads. Sometimes, they also can carry pure axial load and operate in higher speed. Under radial load, axial component force will be produced which must be counteracted. So the bearings are normally adjust against a second bearing.
Advantages :
Ultra clean steel to extend bearing life by up to 80%
Advanced grade technology
Quiet and smooth operation even at high speed
Super finished raceways
Offer products in 15,25 and 40 degree angles
Available in arrange of Polyamide, steel and brass cage assembles
Application:
Application: Angular Contact Ball Bearing is widely used in cars, compressors, construction, electric motors, food industry, home appliances etc. As a rolling element, it turns the world.
