71813ACTAP5GB angular contact ball bearings with low vibration for the spindles

1
MOQ
25USD
Price
71813ACTAP5GB angular contact ball bearings with low vibration for the spindles
Features Gallery Product Description Request A Quote
Features
Specifications
ID: 65mm
OD: 85mm
B: 10mm
Contact Angle: 25
Accuracy: P5
Preload: Medium
Basic Infomation
Place of Origin: CHINA
Brand Name: MONTON
Certification: ISO9001
Model Number: 71813ACTAP5GB
Payment & Shipping Terms
Packaging Details: Singlebox
Delivery Time: 7-35 days
Payment Terms: T/T
Supply Ability: 10000PCS/WEEK
Product Description

71813ACTAP5GB angular contact ball bearings with low vibration for the spindles 0

Ball Bearing - Spindle Bearings

Spindle ball bearings are single-row large ball bearings characterized by their particular design engineered with either a 15° or a 25° angular contact. They contain raceways in both the inner and outer rings which can be displaced in relation to the bearing axis and in relation to each other. These rings are assembled with a stationary cage, and the balls cannot be dismantled from the ball bearing housing.

Spindle ball bearings are designed to provide the utmost support for a number of different types of loads making them popular mining bearings. The mechanism's loading capacity proportionally increases with the augmentation of the contact angle. Due to the device's eminent and relentless accuracy, these ball bearings are often utilized when there is a need for utmost precision, high bearing capacity, high-speed and an impeccable accuracy. As a result, they are primarily used as machine tool spindle bearings and mining bearings.



Models

There are two primary kinds of spindle bearings:

Open Spindle Bearings: These types of spindle bearings contain large balls inside the bearing housing in order to maximize its performance capacity. The external ring in these large ball bearings usually has only one shoulder.

Closed Spindle Bearing: This model has the same external dimensions as open large ball bearings, but is often packed with small balls, reducing the capacity yet increasing the axial rigidity and speed.







  Dimensions Assemnly Dimensions Loading RPM
Weight
Bearings d D B rsmin r1smin da Da ra rb Etk Cdyn C0stat Grease Oil kg
mm mm mm     h12 H12 max max   kN kN min-1 minimal
71800 10 19 5 0.3 0.1 12 17 0.3 0.1 13.3 1.9 0.98 75000 120000 0.005
71801 12 21 5 0.3 0.1 14 19 0.3 0.1 15.3 2.08 1.18 67000 100000 0.01
71802 15 24 5 0.3 0.1 17 22 0.3 0.1 18.3 2.28 1.5 56000 85000 0.01
71803 17 26 5 0.3 0.1 19 24 0.3 0.1 20.3 2.32 1.6 50000 75000 0.01
71804 20 32 7 0.3 0.1 23 29 0.3 0.1 24.5 3.8 2.65 43000 63000 0.02
71805 25 37 7 0.3 0.1 28 34 0.3 0.1 29.5 4.15 3.2 36000 53000 0.02
71806 30 42 7 0.3 0.1 33 39 0.3 0.1 34.5 4.4 3.65 30000 45000 0.03
71807 35 47 7 0.3 0.1 38 44 0.3 0.1 39.5 4.65 4.15 26000 40000 0.03
71808 40 52 7 0.3 0.1 43 49 0.3 0.1 44.5 4.8 4.55 24000 38000 0.03
71809 45 58 7 0.3 0.1 48 55.5 0.3 0.1 49.6 7.2 6.95 22000 36000 0.04
71810 50 65 7 0.3 0.1 54 61.5 0.3 0.1 55.6 7.35 7.35 19000 32000 0.05
71811 55 72 9 0.3 0.1 59 68.5 0.3 0.1 61.2 10.2 10.2 17000 28000 0.08
71812 60 78 10 0.3 0.1 63 74.5 0.3 0.1 66.3 13.2 13.2 16000 26000 0.1
71813 65 85 10 0.6 0.3 69 80.5 0.6 0.3 72.3 13.4 14 15000 24000 0.13
71814 70 90 10 0.6 0.3 74 85.5 0.6 0.3 77.3 14 15 14000 22000 0.14
71815 75 95 10 0.6 0.3 79 90.5 0.6 0.3 82.3 14.3 15.6 13000 20000 0.14
71816 80 100 10 0.6 0.3 84 95.5 0.6 0.3 87.3 14.6 16.6 12000 19000 0.15
71817 85 110 13 1 0.3 90 105 1 0.3 94.1 21.6 24 11000 18000 0.27
71818 90 115 13 1 0.3 95 110 1 0.3 99.4 21.2 23.6 11000 18000 0.28
71819 95 120 13 1 0.3 100 115 1 0.3 104.4 21.6 24.5 10000 17000 0.29
71820 100 125 13 1 0.3 105 120 1 0.3 109.4 21.6 25 9500 16000 0.3
71821 105 130 13 1 0.3 110 125 1 0.3 114.4 22.8 27.5 9000 15000 0.3
71822 110 140 16 1 0.3 116 134 1 0.3 121.2 31.5 36.5 8500 14000 0.5
71824 120 150 16 1 0.3 126 144 1 0.3 131.2 32 39 7500 12000 0.5
71826 130 165 18 1.1 0.6 137 158 1.1 0.6 143.1 42.5 51 7000 11000 0.8
71828 140 175 18 1.1 0.6 147 168 1.1 0.6 153.1 43 54 6300 9500 0.8
71830 150 190 20 1.1 0.6 158 182 1.1 0.6 164.8 56 69.5 6000 9000 1.1
71832 160 200 20 1.1 0.6 168 192 1.1 0.6 174.8 57 73.5 5600 8500 1.2
71834 170 215 22 1.1 0.6 179 206 1.1 0.6 186.7 68 88 5000 7500 1.6
71836 180 225 22 1.1 0.6 189 216 1.1 0.6 196.7 71 93 4800 7000 1.7
71838 190 240 24 1.5 0.6 201 229 1.5 0.6   80 108 4500 6700 2.2
71840 200 250 24 1.5 0.6 211 239 1.5 0.6 218.9 81.5 114 4300 6300 2.3
71844 220 270 24 1.5 0.6 231 259 1.5 0.6       3800 5600 2.5
71848 240 300 28 2 1 253 287 2 1 262.8 106 150 3400 5000 3.9
