Item: 7206B Ball Bearings
Type: Single Row Angular Contact Ball Bearings(Spindle Ball Bearings)
Dimensions: 30mm x 62mm x 16mm/Metric
inner diameter: 30 mm
outer diameter: 62 mm
Width: 16mm
Size: 30mm x 62mm x 16mm
Quantity: Two High speed
Dynamic load rating Cr: 21,200N
Static load rating Cor: 13,900N
Limiting Speed:
Grease Lubrication: 8,500RPM
Oil Lubrication: 12,000 RPM
Single Row Angular Contact Ball Bearings are self-retaining units. They have solid inner and outer rings and ball and cage assemblies with polyamide, sheet metal or brass cages. The raceways of the inner and outer rings are offset from each other along the bearing axis. The bearings are available in open and sealed designs. Their angular adjustment facility is limited.
Features and Benefits
• Lower operating costs • Reduced maintenance due to improved lubrication
• Lower heat generation
• Less noise
Product Application Information
In certain applications, a smaller bearing arrangement can be designed. Single row angular contact ball bearings can support axial forces in one direction and high radial forces. They must be axially adjusted against another bearing fitted in a mirror image arrangement
Suffixes
B - Modified internal construction
TVP - Solid cage made from glass fibre reinforced polyamide
