NCF1830V For Crane Sheaves Full Complement Cylindrical Roller Bearing Single Row Series

1
MOQ
USD
Price
NCF1830V For Crane Sheaves Full Complement Cylindrical Roller Bearing Single Row Series
Features Gallery Product Description Request A Quote
Features
Specifications
Material: GCr15 Or GCr15SiMn
Application: Gear Box Producers, Transmission Motor, Producers Steel Industry
Accuracy: P0 Or P6 Or P5
Dimension: 150*190*20mm
Market: Europe,USA,Japan,Korean
High Light:

sealed cylindrical roller bearings

,

cylindrical thrust bearing

Basic Infomation
Place of Origin: LUOYANG
Brand Name: MONTON
Certification: ISO9001
Model Number: NCF1830V
Payment & Shipping Terms
Packaging Details: Single box/Wooden case
Delivery Time: 7-35 days
Payment Terms: TT
Supply Ability: 1000/pcs/week
Product Description

Full Complement Cylindrical Roller Bearings











Full complement cylindrical roller bearings can withstand extremely high stresses at lower speeds. Unsealed single and double row bearings are used mainly in gear boxes. These cageless bearings are marked with the code letter V.



Cylindrical roller bearing main application :

Full-complement cylindrical roller bearings for crane sheaves
Gear box producers
Transmission motor producers
Steel industry
Producers for construction equipment
Forest technology
Synthetic material industry
Machine tool producers
Producers of measuring devices and dividing units
Rotary table manufactures
Maritime industry
Metal forming technology
Crane sheave on the sea
Deck crane
Transmission
Planetary speed reducer
Code Dimension Load rating Weight ≈
static dynamic
  d
mm
D
mm
B
mm
C0
kN
C
kN

kg
NCF1830V 150 190 20 213 116 1,3
NCF1832V 160 200 20 233 121 1,5
NCF1834V 170 215 22 272 149 1,8
NCF1836V 180 225 22 277 141 2
NCF1838V 190 240 24 331 173 2,5
NCF1840V 200 250 24 332 174 3,5
NCF1844V 220 270 24 435 221 3
NCF1848V 240 300 28 548 265 4,5
NCF1852V 260 320 28 561 275 4,8
NCF1856V 280 350 33 735 367 7,5
NCF1860V 300 380 38 885 438 11
NCF1864V 320 400 38 912 442 11
NCF1868V 340 420 38 980 460 11,5
NCF1872V 360 440 38 1.043 490 12
NCF1876V 380 480 46 1.343 629 20
NCF1880V 400 500 46 1.396 642 21
NCF1884V 420 520 46 1.454 657 22
NCF1888V 440 540 46 1.446 629 22
NCF1892V 460 580 56 1.723 845 35
NCF1896V 480 600 56 1.866 856 36
NCF18/500V 500 620 56 2.013 882 37
NCF18/530V 530 650 56 2.318 1.014 36,5
NCF18/560V 560 680 56 2.418 1.073 41
NCF18/600V 600 730 60 2.613 1.079 50
NCF18/630V 630 780 69 3.148 1.405 72
NCF18/670V 670 820 69 3.477 1.444 75
NCF18/710V 710 870 74 3.730 1.540 90
NCF18/750V 750 920 78 4.580 1.932 110
Code Dimension Load rating Weight ≈
static dynamic
  d
mm
D
mm
B
mm
C0
kN
C
kN

kg
NCF2208V 40 80 23 68 60 0,6
NCF2209V 45 85 23 88 75 0,6
NCF2210V 50 90 23 114 94 0,7
NCF2211V 55 100 25 136 112 0,9
NCF2212V 60 110 28 164 133 1,2
NCF2213V 65 120 31 195 155 1,6
NCF2214V 70 125 31 227 176 1,7
NCF2215V 75 130 31 266 206 1,8
NCF2216V 80 140 33 306 234 2,2
NCF2217V 85 150 36 349 264 2,8
NCF2218V 90 160 40 395 295 3,5
NCF2219V 95 170 43 444 328 4,2
NCF2220V 100 180 46 536 384 5,1
NCF2222V 110 200 53 563 424 7,2
NCF2224V 120 215 58 637 462 9,1
NCF2226V 130 230 64 879 610 11
NCF2228V 140 250 68 1.032 706 14,5
NCF2230V 150 270 73 1.199 810 19
NCF2232V 160 290 80 1.380 1.097 23
NCF2234V 170 310 86 1.679 1.097 29
NCF2236V 180 320 86 1.781 1.137 30
NCF2238V 190 340 92 1.970 1.248 36
NCF2240V 200 360 98 2.247 1.332 45
Code Dimension Load rating Weight ≈
static dynamic
  d
mm
D
mm
B
mm
C0
kN
C
kN

kg
NCF2912V 60 85 16 68 40 0,3
NCF2913V 65 90 16 71 43 0,3
NCF2914V 70 100 19 114 75 0,5
NCF2915V 75 105 19 121 78 0,6
NCF2916V 80 110 19 129 80 0,6
NCF2917V 85 120 22 162 101 0,9
NCF2918V 90 125 22 172 104 0,9
NCF2919V 95 130 22 181 123 0,9
NCF2920V 100 140 24 221 130 1,2
NCF2922V 110 150 24 240 136 1,3
NCF2924V 120 165 27 293 172 1,7
NCF2926V 130 180 30 356 205 2,3
NCF2928V 140 190 30 378 211 2,5
NCF2930V 150 210 36 503 289 3,9
NCF2932V 160 220 36 534 298 4,2
NCF2934V 170 230 36 566 307 4,3
NCF2936V 180 250 42 693 390 6,3
NCF2938V 190 260 42 736 403 6,8
NCF2940V 200 280 48 956 527 9,1
NCF2944V 220 300 48 994 517 10
NCF2948V 240 320 48 1.077 539 11
NCF2952V 260 360 60 1.434 742 19
NCF2956V 280 380 60 1.711 870 20
NCF2960V 300 420 72 2.199 1.117 32
NCF2964V 320 440 72 2.356 1.164 33
NCF2968V 340 460 72 2.475 1.190 36
NCF2972V 360 480 72 2.613 1.224 38
NCF2976V 380 520 82 3.266 1.576 53
NCF2980V 400 540 82 3.454 1.623 55
NCF2984V 420 560 82 3.551 1.646 58
NCF2988V 440 600 95 4.373 2.011 82
NCF2992V 460 620 95 4.400 2.095 85
NCF2996V 480 650 100 5.042 2.289 100
NCF29/500V 500 670 100 5.204 2.610 100
NCF29/530V 530 710 106 5.604 2.426 120
NCF29/560V 560 750 112 6.581 2.867 142
NCF29/600V 600 800 118 7.375 3.270 172
NCF29/630V 630 850 128 8.575 3.745 208
NCF29/670V 670 900 136 9.000 3.855 250
NCF29/710V 710 950 140 10.200 4.395 280
NCF29/750V 750 1.000 145 11.004 4.592 320
Code Dimension Load rating Weight ≈
static dynamic
  d
mm
D
mm
B
mm
C0
kN
C
kN

kg
NCF3008V 40 68 21 68 57 0,3
NCF3009V 45 75 23 76 60 0,5
NCF3010V 50 80 23 105 70 0,5
NCF3011V 55 90 26 131 98 0,7
NCF3012V 60 95 26 138 101 0,7
NCF3013V 65 100 26 151 107 0,8
NCF3014V 70 110 30 180 127 1
NCF3015V 75 115 30 196 139 1,1
NCF3016V 80 125 34 235 164 1,5
NCF3017V 85 130 34 262 177 1,6
NCF3018V 90 140 37 303 211 2
NCF3019V 95 145 37 300 207 2,1
NCF3020V 100 150 37 308 209 2,2
NCF3022V 110 170 45 397 274 3,7
NCF3024V 120 180 46 435 289 4
NCF3026V 130 200 52 616 414 5,8
NCF3028V 140 210 53 720 458 6,2
NCF3030V 150 225 56 705 467 7,5
NCF3032V 160 240 60 842 538 9,3
NCF3034V 170 260 67 1.054 669 12,5
NCF3036V 180 280 74 1.350 827 16,5
NCF3038V 190 290 75 1.328 809 17
NCF3040V 200 310 82 1.509 910 23
NCF3044V 220 340 90 1.820 1.120 30
NCF3048V 240 360 92 1.956 1.142 32
NCF3052V 260 400 104 2.597 1.568 48
NCF3056V 280 420 106 2.976 1.725 50
NCF3060V 300 460 118 3.628 2.076 70
NCF3064V 320 480 121 3.657 2.068 75
NCF3068V 340 520 133 4.150 2.370 100
NCF3072V 360 540 134 4.945 2.650

108
