VU140179 Slewing Ring Turntable  High Precision Cross Roller Bearing Without Gear Teeth

1
MOQ
USD
Price
VU140179 Slewing Ring Turntable  High Precision Cross Roller Bearing Without Gear Teeth
Features Gallery Product Description Request A Quote
Features
Specifications
Material: 50Mn Or 42CrMo
Dimension: 1424x1509x68 Mm
Delivery: 35working Days
Accuracy: P0 Or P6
High Light:

axial ball bearing

,

ball bearing slewing ring

Basic Infomation
Place of Origin: LUOYANG
Brand Name: MONTON
Certification: ISO9001
Model Number: VU140179
Payment & Shipping Terms
Packaging Details: Single box/Wooden case
Delivery Time: 7-35 days
Payment Terms: TT
Supply Ability: 1000/pcs/week
Product Description

Four Point Contact Slewing Ring Bearing









Specification of Bearing
Bearing type four point contact slewing ring bearing
Brand type GQZ or OEM
Precision Rating P0,P6
Place of origin China
Vibration Z1V1,Z2V2,Z3V3
Durability Long
Material 50Mn or 42CrMo
Certificate ISO9001:2008
Main market abroad

South America,USA,European,Southeast

Asia,Middle East

Packaging Details

1. inner: polyester bag outer:paper carton

2. industrial standard packing

3. Poly bag+box+packing

4. 4. as your order

Delivery Time

W35days

Payment Terms T/T,Western Union,Paypal



Feature:

(1) Four point contact type

(2) Without gear teeth

(3) Good quality

(4) Competitive price

(5) Quick delivery



In the same time,we can also supply the below goods:



Bearing Type Boundary dimensions (mm) Gear Teeth
Nongeared External Gear Internal Gear D d H D1 d1 dn n n1 H1 h b m
010.20.250 011.20.250   330 170 60 298 202 16 18 2 50 10 40 4
010.20.280 011.20.280   360 200 60 328 232 16 18 2 50 10 40 4
010.25.315 011.25.315 013.25.315 408 222 70 372 258 18 20 2 60 10 50 5
010.25.355 011.25.355 013.25.355 448 262 70 412 298 18 20 2 60 10 50 5
010.25.400 011.25.400 013.25.400 493 307 70 457 343 18 24 2 60 10 50 6
010.25.450 011.25.450 013.25.450 543 357 70 507 393 18 24 2 60 10 50 6
010.30.500 011.30.500 013.30.500 602 398 80 566 434 18 20 4 70 10 60 5
012.30.500 014.30.500 602 398 80 566 434 18 20 4 70 10 60 6
010.30.560 011.30.560 013.30.560 662 458 80 626 494 18 20 4 70 10 60 5
012.30.560 014.30.560 662 458 80 626 494 18 20 4 70 10 60 6
010.30.630 011.30.630 013.30.630 732 528 80 696 564 18 24 4 70 10 60 6
012.30.630 014.30.630 732 528 80 696 564 18 24 4 70 10 60 8
010.30.710 011.30.710 013.30.710 812 608 80 776 644 18 24 4 70 10 60 6
012.30.710 014.30.710 812 608 80 776 64 18 24 4 70 10 60 8
010.40.800 011.40.800 013.40.800 922 678 100 878 722 22 30 6 90 10 80 8
012.40.800 014.40.800 922 678 100 878 722 22 30 6 90 10 80 10
010.40.900 011.40.900 013.40.900 1022 778 100 978 822 22 30 6 90 10 80 8
012.40.900 014.40.900 1022 778 100 978 822 22 30 6 90 10 80 10
010.40.1000 011.40.1000 013.40.1000 1122 878 100 1078 922 22 36 6 90 10 80 10
012.40.1000 014.40.1000 1122 878 100 1078 922 22 36 6 90 10 80 12
010.40.1120 011.40.1120 013.40.1120 1242 998 100 1198 1042 22 36 6 90 10 80 10
012.40.1120 014.40.1120 1242 998 100 1198 1042 22 36 6 90 10 80 12
010.45.1250 011.45.1250 013.45.1250 1390 1110 110 1337 1163 26 40 5 100 10 90 12
012.45.1250 014.45.1250 1390 1110 110 1337 1163 26 40 5 100 10 90 14
010.45.1400 011.45.1400 013.45.1400 1540 1260 110 1487 1313 26 40 5 100 10 90 12
012.45.1400 014.45.1400 1540 1260 110 1487 1313 26 40 5 100 10 90 14
010.45.1600 011.45.1600 013.45.1600 1740 1460 110 1687 1513 26 45 5 100 10 90 14
012.45.1600 014.45.1600 1740 1460 110 1687 1513 26 45 5 100 10 90 16
