30101 Taper Roller Bearing RV Reducer Bearing

Product Details:

Place of Origin:	Luoyang
Brand Name:	MONTON
Certification:	ISO9001
Model Number:	30101

Detail Information

Place of Origin:

Luoyang

Brand Name:

MONTON

Certification:

ISO9001

Model Number:

30101

Trading Information

Minimum Order Quantity:

1 PCS

Price:

Negotiable

Packaging Details:

Single Box

Delivery Time:

5days to 35days

Payment Terms:

L/C, D/A, D/P, T/T

Supply Ability:

10000 PCS Per Week

Product Description

Name	Taper roller bearing
Seires	Single row
Brand	MONTON
Model	30101
d	12mm
D	27mm
T	13mm
Ring Material	Gcr15/carburizing steel
Cage Material	brass/Brass
Load rating Cr	13.4kN
Load rating Cor	12.8kN
Sealed	NO
Design Structure	Taper roller
Precision	P4,P5 or according to requirement
Vibration	ZV1, ZV2, ZV3, or as requirement
Clearance	C0, C2, C3, or as customer requirement
Quality standard	ISO9001: 2000/SGS RoHS ect.
Package	Single Box
Original	Luoyang
Service	OEM
Delivery date	Stock
Application	Machine tools Centrifuges Manipulators Hoists Luggage scanner Medical technology Antennas such as radar systems and telescopes Automation, such as robot and handling systems

30101 Taper Roller Bearing RV Reducer Bearing 0

Introduction:
Tapered roller bearings have tapered inner and outer ring raceways as well as tapered rollers They are designed to accommodate combined loads, i.e. simultaneously acting radial and axial loads The projection lines of the raceways meet at a common point on the bearing axis to provide a true rolling action and therefore low frictional moments during operation The axial load carrying capacity of tapered roller bearings increases with increasing contact angle α The size of the contact angle, which is usually between 10° and 30°, is related to the calculation factor e : the larger the value of e, the larger the contact angle.

Bearing feature:
1.Low friction
2.Long service life
3.Enhanced operational reliability
4.Consistency of roller proiles and sizes
5.Rigid bearing application
6.Running-in period with reduced temperature peaks
7.Separable and interchangeable
