L163149 / L163110 Single Row Angular Contact Ball Bearings Imperial Design Units

Product Details:

Detail Information

Place of Origin:

CHINA

Brand Name:

MONTON

Certification:

ISO9001

Model Number:

L163149 / L163110

Name:

L163149 / L163110

396.875

549.275

T174.625:

38.1

Weight:

58.6KG

Keywords:

China Single Row Angular Contact Ball Bearings Manufacturers

Highlight:

High Light

Highlight:

Trading Information

Minimum Order Quantity:

Price:

USD

Packaging Details:

Singlebox

Delivery Time:

7-35 days

Product Description

L163149 / L163110

R - Cone Backface "To Clear" Radius¹	0.25 in6.400 mm
r - Cup Backface "To Clear" Radius²	0.130 in3.30 mm
da - Cone Frontface Backing Diameter	16.54 in420.10 mm
db - Cone Backface Backing Diameter	16.93 in430 mm
Da - Cup Frontface Backing Diameter	21.02 in531.11 mm
Ab - Cage-Cone Frontface Clearance	0.19 in4.8 mm
Aa - Cage-Cone Backface Clearance	0.45 in11.4 mm
a - Effective Center Location³	0.61 in15.5 mm

C90 - Dynamic Radial Rating (90 million revolutions)⁴	83500 lbf371000 N
C1 - Dynamic Radial Rating (1 million revolutions)⁵	322000 lbf1430000 N
C0 - Static Radial Rating	704000 lbf3130000 N
C_a90 - Dynamic Thrust Rating (90 million revolutions)⁶	58200 lbf259000 N

K - Factor⁷	1.43
e - ISO Factor⁸	0.41
Y - ISO Factor⁹	1.47
G1 - Heat Generation Factor (Roller-Raceway)¹⁰	3800
G2 - Heat Generation Factor (Rib-Roller End)	427
Cg - Geometry Factor¹¹	0.214
