| Model | WORM DRIVE HSE25 |
| Worm Drive Performance Parameters | |
| ID | 512 |
| OD | 889 |
| H | 148 |
| Output Torque | 25 kN.m |
| Tilting MomentTorque | 30 kN.m |
| Holding Torque | 271 kN.m |
| Static Axial Rating | 2360 kN |
| Static Radial Rating | 945 kN |
| Dynamic Axial Rating | 590 kN |
| Dynamic Radial Rating | 470 kN |
| Gear Ratio | 94: 1 |
| Tracking Precision | ≤ 0.15° |
| Input | Ø40 |
| END CAP | |
| Weight | 255kg |
| CUSTOMIZED ACCORDING TO REQUESTS | |
| APPLICATION | Slewing Drive for solar tracking system |
| Slewing Drive for PV Application | |
| Slewing Drive for Construction Machinery Application | |
| Aerial working platform | |
| Manlifts, Skylifts | |
| Telescopic boom skylifts | |
| Articulating boom skylifts | |
| Truck mounted crane | |
| lorry loaders | |
| Loader cranes | |
| Marine cranes | |
| Hydraulic grapples | |
| forklift attachments | |
| woods log grapple | |
| single axis solar tracker | |
| dual axis solar tracker | |
| solar tracking system | |
Slewing drive
The slewing drive is a gearbox that can safely hold radial and axial loads, as well as transmit a torque for rotating. The rotation can be in a single axis, or in multiple axes together. Slewing drives are made by manufacturing gearing, bearings, seals, housing, motor and other auxiliary components and assembling them into a finished gearbox.
Special Slewing Drive Vertical Type
VE means vertical installation slewing drive, mainly apply to the high working condition requirement for dust proof, rain-proof and anti-corrosion occasion. Precision grade IP65.
The Slewing Drive can be used for any occasion where the need for full-cycle rotation and variable speed requirements. When the need for larger torque power transmission, the higher accuracy of the motion transmission or the compact structure of the body requires a higher mechanism selection, the rotary drive Is the best solution.Enclosed dual axis slewing drive can realize the movement in two different direction,vertically and horizontally. Usually apply to the dual axis solar tracking systems or some machinery equipment with similar working condition.
Application:
Slewing Drive for solar tracking system
Slewing Drive for PV Application
Slewing Drive for Construction Machinery Application
Aerial working platform
Manlifts, Skylifts
Telescopic boom skylifts
Articulating boom skylifts
Truck mounted crane
lorry loaders
Loader cranes
Marine cranes
Hydraulic grapples
forklift attachments
woods log grapple
single axis solar tracker
dual axis solar tracker
solar tracking system
