700CTYNDULP4 FAG Angular Contact Bearing Light Preload For Industrial Actuators
1pcs
MOQ
USD
Price
700CTYNDULP4 FAG Angular Contact Bearing Light Preload For Industrial Actuators
Features Gallery Product Description Request A Quote
Features
Basic Infomation
Place of Origin: Luoyang
Brand Name: Monton
Model Number: 7005BP5/UL 7210B/UL 7206B/UL
High Light:

angular contact thrust bearing

,

thin section angular contact bearings

Payment & Shipping Terms
Packaging Details: Single box/Wooden case
Delivery Time: 7-35 days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 10000PCS/WEEK
Specifications
Product Description



7005BP5/UL 7210B/UL 7206B/UL with steel or brass cage light preload

for INDUSTRIAL ACTUATORS



7005B Single Row Angular Contact Spindle Ball Bearing, this is a popular size that could be used in many applications that needs Cobined loads (Axial and Radial), Axial loads can be taken on one direction only.Bearing is made of Chrome Steel.

  • Item:7005BP5/UL
  • Type: Single Row Angular Contact Ball Bearing (Spindle Ball Bearing)
  • Dimensions: 25mm x 47mm x 12mm/metric
  • inner diameter: 25mm
  • outer diameter: 47mm
  • Width: 12mm
  • Size: 25 x 47 x 12 mm
  • Quantity:One Bearing
  • Dynamic load rating Cr: 11,300 N
  • Static load rating Cor: 7,400 N
  • Limiting Speed:
    • Grease Lubrication: 13,000 RPM
    • Oil Lubrication: 17,000 RPM

700CTYNDULP4 FAG Angular Contact Bearing Light Preload For Industrial Actuators 0

Best-in-Class Lifetime
700CTYNDULP4 FAG Angular Contact Bearing Light Preload For Industrial Actuators 1
Designed and manufactured under stringent quality standards, Diakont EMAs incorporate optimized roller screw thread design and specialized hardening technologies to provide a best-in-class service lifetime rating. With a greater number of contact points than ball screw solutions, Diakont hardened roller screws feature increased load capacity and rigidity, providing superior operating lifetime compared to ball screw (up to 10x greater lifetime) and competitor roller screw actuators on the market.

Diakont is a full-cycle engineering, manufacturing, and service company, supplying motion control solutions that enhance the safety, economy and efficiency of many industries.



High-Performance Actuation in a Small Package
700CTYNDULP4 FAG Angular Contact Bearing Light Preload For Industrial Actuators 2

Diakont EMAs are equipped with inverted roller screws, which require much less space than ball screw or pneumatic solutions with equivalent specifications (force, speed, etc.). Owing to this optimized design, Diakont actuators require smaller housings and fewer parts between the motor and the roller screw, thereby reducing the overall weight and size of the EMA. The Diakont DA Series actuator line of reduced weight starts at 5 kg.

Easy Installation and Maintenance
700CTYNDULP4 FAG Angular Contact Bearing Light Preload For Industrial Actuators 3


The DA Series’ compact design allows end users to easily replace hydraulic or pneumatic actuators with Diakont EMAs. Diakont EMAs are compatible with various third party servo drives and amplifiers. As a result, Diakont actuators allow for easy integration into existing motion control systems.

Diakont DA Series actuators are also equipped with specialized patented lubrication ports that facilitate scheduled maintenance without requiring disassembly, recalibration, or removal from machinery. Performing maintenance with the actuator on the machine reduces downtime and improves output.
