7902A5 15x28x7mm Angular contact ball bearing Encoder Bearing Temperature Sensor Bearing

1
MOQ
USD
Price
7902A5 15x28x7mm Angular contact ball bearing  Encoder Bearing Temperature Sensor Bearing
Features Gallery Product Description Request A Quote
Features
Specifications
Basic Infomation
Place of Origin: CHINA
Brand Name: MONTON
Certification: ISO9001
Model Number: 7902A5
Payment & Shipping Terms
Packaging Details: Singlebox
Delivery Time: 7-35 days
Payment Terms: T/T
Supply Ability: 10000PCS/WEEK
Product Description

Angular contact ball bearings 7902 A5
Bearing number : 7902 A5

Size (mm) : 15x28x7

Brand : MONTON

Bore Diameter (mm) : 15

Outer Diameter (mm) : 28

Width (mm) : 7

Bearing dimensions and specification in NSK catalogue:

d - 15 mm

D - 28 mm

B - 7 mm

C - 7 mm

a - 8,5 mm

r min. - 0,3 mm

r1 min. - 0,15 mm

da min. - 17,5 mm

Da max. - 25,5 mm

ra max. - 0,3 mm

Weight - 0,015 Kg

Basic dynamic load rating (C) - 4,55 kN

Basic static load rating (C0) - 2,53 kN

(Grease) Lubrication Speed - 32 000 r/min

(Oil) Lubrication Speed - 43 000 r/min





Product Description
Angular contact ball bearings have raceways on the inner and outer rings, and the inner and outer rings can be relatively displaced along the bearing axis.This type of bearing is particularly suitable for bearing compound loads, that is, loads acting both radially and axially. The axial load bearing capacity of angular contact ball bearings increases with the increase of the contact angle α.
Single row angular contact ball bearings can only bear axial load in one direction. When bearing radial load, additional axial force will be caused. And it can only li mit the axial displacement of the shaft or housing in one direction. Angular contact ball bearings have a contact angle of 40 degrees, so they can withstand large axial loads. Angular contact ball bearings are of non-separable design, and the shoulders on both sides of the inner and outer rings are different in height.
Double row angular contact ball bearings can withstand large radial loads, mainly combined radial and axial loads and moment loads, limiting the axial displacement of the shaft on both sides. The tiltability between the inner and outer rings of the double row angular contact ball bearing is mainly used to limit the bidirectional axial displacement of the shaft and the housing. The allowable tilt angle depends on the internal clearance of the bearing, bearing size, internal design and acting on it. The force and moment on the bearing, and the maximum allowable inclination angle should ensure that no excessive additional stress is generated in the bearing. If there is an inclination angle between the inner and outer rings of the bearing, it will affect the life of the bearing, and at the same time cause the bearing's running accuracy to decrease and the running noise to increase. Double row angular contact ball bearings generally use nylon cages or brass solid cages.

A wide range of applications:

• agriculture and forestry equipment
• automotive and industrial gearboxes
• automotive and truck electric components, such as alternators
• electric motors
• fluid machinery
• material handling
• power tools and household appliances
• textile machinery
• two Wheeler.
