29244EM Self Aligning Thrust Bearing  Single Row High Speed Thrust Bearing

1
MOQ
USD
Price
29244EM Self Aligning Thrust Bearing   Single Row High Speed Thrust Bearing
Features Gallery Product Description Request A Quote
Features
Specifications
Material: GCr15 Or GCr15SiMn
Accuracy: P6 Or P5
Market: USA Or Euro Market
Dimension: 220*300*48mm
High Light:

radial thrust bearing

,

smooth thrust bearing

Basic Infomation
Place of Origin: LUOYANG
Brand Name: MONTON
Certification: ISO9001
Model Number: 29240EM
Payment & Shipping Terms
Packaging Details: Single box/Wooden case
Delivery Time: 7-35 days
Payment Terms: TT
Supply Ability: 1000/pcs/week
Product Description

Thrust Roller Bearings Features:

1): Able to accommodate misalignment
2): Suitable for high axial and some radial loads
3): Relatively high speed ratings

4): Heavy machine tools, high power Marine gearbox, oil rig, vertical motor machinery, Juki hooks,

vertical pumps, vertical centrifuge, jack, low speed reducer



Description of thrust spherical roller bearings:

1.single row, self-aligning roller bearings

2. They comprise solid shaft and housing washers and asymmetrical barrel rollers with cages.

3. The cage holds the roller and cage assembly together with the shaft locating washer.

4. The bearings can be dismantled. The parts of the bearings can be fitted separately.

5. Spherical roller thrust bearings can support very high axial loads and permit relatively high speeds. Since the raceways are at an angle to the bearing axis, the bearings can also support radial loads.



Thrust spherical roller bearings designs:

Bearings are produced in several designs which is mainly different in cage as following:

Bearings in "M" design have brass cages guided by a steel sleeve on the shaft washer.

Bearings in "J" design have pressed steel cages guided on the shaft washer.

Bearings in "J" design are interchangable with bearings with machined brass cage. If the bearings with machined brass cage is to be replaced in arrangement, where the shaft washer rests on the shaft on the face of steel sleeve which guides the cage by the bearings in "J" design, it is necessay to insert a spacer between the shaft washer and original shaft shoulder.



Code Dimension Load rating Weight ≈
static dynamic
  d
mm
D
mm
T
mm
C0
kN
C
kN

kg
29240E.MB 200 280 48 2.650 654 9,1
29244E.MB 220 300 48 3.100 705 9,8
29248E.MB 240 340 60 3.800 880 17,1
29252E.MB 260 360 60 4.060 900 18,5
29256E.MB 280 380 60 4.400 950 19,5
29260E.MB 300 420 73 5.361 1.190 31
29264E.MB 320 440 73 5.654 1.260 32,8
29268E.MB 340 460 73 6.032 1.350 34,5
29272E.MB 360 500 85 7.514 1.600 50,5
29276E.MB 380 520 85 7.700 1.790 52,8
29280.E.MB 400 540 85 8.800 1.840 55,1
29284E.MB 420 580 95 10.800 2.200 74,9
29288E.MB 440 600 95 11.470 2.300 79
29292E.MB 460 620 95 11.700 2.350 80,9
29296E.MB 480 650 103 12.800 2.550 97,5
292/500E.MB 500 670 103 13.600 2.600 101
292/530E.MB 530 710 109 15.600 3.090 120
292/560E.MB 560 750 115 17.200 3.250 141
292/600E.MB 600 800 122 19.400 3.800 168
292/630E.MB 630 850 132 22.000 4.350 212
292/670E.MB 670 900 140 24.000 4.650 249
292/710E.MB 710 950 145 28.500 5.600 285
292/750E.MB 750 1.000 150 31.500 5.800 323
292/800E.MB 800 1.060 155 36.000 6.540 369
292/850E.MB 850 1.120 160 39.500 7.050 419
292/900E.MB 900 1.180 170 43.000 8.000 488
292/950E.MB 950 1.250 180 48.000 8.650 585
