H7005CP42RZ 25x47x12mm CNC spindle router bearing angular contact bearings
1
MOQ
USD
Price
H7005CP42RZ 25x47x12mm CNC spindle router bearing angular contact bearings
Features Gallery Product Description Request A Quote
Features
Basic Infomation
Place of Origin: LUOYANG
Brand Name: MONTON
Certification: ISO9001
Model Number: H7005CP42RZ
High Light:

dental ball bearing

,

high precision bearings

Payment & Shipping Terms
Packaging Details: Single box/Wooden case
Delivery Time: 7-35 days
Payment Terms: TT
Supply Ability: 1000/pcs/week
Specifications
Ring Material: GCR15 Or 440C Or 9Cr18Mo
Ball Material: Ceramic Ball Or Steel Ball
Accuracy: P4 Or P2
Speed: 400000RPM
Application: Dentall Drill Industry Or Mobile Phone
Market: Germany,Spain,Brazil
Packing: Vacuum Package, Tube
HS: 8482102000
Number Of Row: Single Row
Precision Rating: P4
Seals Type: Open,ZZ 2RS OPEN
Structure: Angular Contact
Type: Ball
Material: Chrome Steel,stainless Steel,carbon Steel,ZrO2,Bearing Steel
Service: OEM Customized Services
Cage: Nylon Cage
Feature: Long Life,High Speed,low Noise,durable,Low Price
Product Description

Single row angular contact ball bearing:



Overview:



Only bear a direction of axial load. This kind of bearing under pure radial load, due to rolling body load line of action and radial load line of action is not the same radial plane inside, produce internal axial component, so must be paired installation and use



Structure:



Belong to separable angular contact ball bearing,this kind of bearing code is S70000.



The outer roll roadside no lock, and inner ring, cage, steel ball component separation, and therefore can be installed respectively.



Paired configuration of angular contact ball bearing have three kinds of different configuration pattern:



(a) Back-to-back configuration,rear code is DB, The configuration of the rigid good, bear overturning moment performance good, bearing can be subject to bi-directional load



(b) Face to face configuration,rear code is DF, This configuration rigidity and the ability to withstand overturning moment as DB configuration form, the bearing can be subject to bi-directional load



(c) Series configuration,rear code is DT, This configuration also available in the same bearing place series three or more bearing, but only under single direction of the axial load



H7005CP42RZ 25x47x12mm CNC spindle router bearing angular contact bearings 0
