230/630 CA/W33 Spherical Thrust Roller Bearing , Low Noise Low Friction Bearings

Minimum Order Quantity : 1pcs Price : USD
Packaging Details : Single box/Wooden case Delivery Time : 7-35 days
Place of Origin: LUOYANG Brand Name: MONTON
Model Number: 230/630 CA/W33

Detail Information

Name: China Heavy Duty Spherical Thrust Roller Bearing Suppliers
High Light:

radial roller bearing

,

stainless steel spherical bearings

Product Description

230/630 CA/W33

230/630 CA/W33 Spherical Thrust Roller Bearing , Low Noise Low Friction Bearings 1230/630 CA/W33 Spherical Thrust Roller Bearing , Low Noise Low Friction Bearings 2

d   630 mm
D   920 mm
B   212 mm
d2 727 mm
D1 839 mm
b   22.3 mm
K   12 mm
r1,2 min. 7.5 mm



da min. 658 mm
Da max. 892 mm
ra max. 6 mm



Calculation data
Basic dynamic load rating C   6898 kN
Basic static load rating C0   12500 kN
Fatigue load limit Pu   780 kN
Reference speed     380 r/min
Limiting speed     670 r/min
Calculation factor e   0.21
Calculation factor Y1   3.2
Calculation factor Y2   4.8
Calculation factor Y0   3.2
Mass
Mass bearing     485

kg







Quality system: In the process of manufacturing spherical roller bearings, we have 11 quality control points.

1. Batch test of material

2. Full-inspection of forging

3. Full-inspection of lathing

4. Batch test of Heat Treatment

5. Full-inspection of grinding dimension

6. Full-inspection of groove grinding

7. Full inspection of semi-finished products

8. Batch test of other components

9. Full-inspection of the dimension before assembling

10. Full-inspection of vibration

11. Batch test before leaving factory



The inner ring of spherical roller bearings have two raceways, outer raceway is a part of a sphere, whose curvature center is on the axis of bearings. This type of bearings possesses self-aligning performance, allowing the misalignment of shaft, and can also be used under certain permanent misalignment. These bearings are able to carry higher radial loads, as well as certain axial loads, but can’t be used to carry pure axial loads. The osculation between rollers and raceways is high, and friction is higher than cylindrical roller bearings. Therefore, the limiting speed is lower. This type of bearings is especially suitable to the heavy or vibrating load applications. The type 20000C bearings have symmetrical rollers and pressed steel cages, no rib on inner ring, rollers are longer, load carrying capacity is high, and rollers are guided by a floating guide ring. The type 20000CC bearings are the modified type to type 20000C, the friction between rollers and raceway is decreased, load carrying capacity is enhanced. The type 20000CA bearings adopt symmetrical spherical rollers and machined solid cages, they have floating guide ring and integral ribs on inner rings. The type 20000TN1 bearings use symmetrical rollers and nylon molded cages, no integral ribs and floating guide ring on inner ring, the cages are guided by rollers. The type 20000CC, 20000CA and 20000TN1 bearings are developed in recent years and their internal design are optimized, should give priority to be used. Spherical roller bearings are primarily used in the applications, such as rolling mills, paper-making, power transmitting equipments and ship mechanics, gearbox, vibratory,Metallurgical Mining and construction Fluid machinery Material handling Industrial gearboxes Textile industry Railways Energy Rigid stranders Tubular stranders Bow skip stranders Double Twist Bunchers Drum Twister Stranders Planetary stranders
