YRT200 yrt rotary table bearings factory

Minimum Order Quantity : 1pcs Price : USD
Packaging Details : Single box/Wooden case Delivery Time : 7-35 days
Supply Ability : 1000pcs/week
Place of Origin: Luoyang Brand Name: Monton
Certification: ISO9001 Model Number: YRT200

Detail Information

High Light:

heavy duty turntable bearings

,

skf turntable bearings

Product Description

YRT200  yrt rotary table bearings factory 0YRT200  yrt rotary table bearings factory 1



bearing type Dimensions fixing holes
d D H H1 C D1 J J1 inner ring outer ring
unit: mm d1 d2 a qty d3 qty
mm mm
YRT200 200 300 45 30 15 274 215 285 7 11 6.2 46 7 45



bearing type Number of retaining screws Extraction thread hole Number of pitches X angle of pitches Screw tightening torque Basic load rating Limiting speed Bearing frictional torque weight
axial radial
dynamic load static load dynamic load static load
MA2) Ca Coa Cr Cor grease
G qty qty×t Nm KN r/min Nm Kg
YRT200 2 M8 3 48×7.5° 14 120 765 81.5 220 260 14 9.7



Machining tolerances for shafts
Bearings shaft diameter (mm) roundness(○) perpendicularity(⊥) parallelism(∥) roughness Ra
Nominal dimension upper lower t1(µm) t3(µm) t4(µm) Ra(µm)
YRT200 200 0 -0.02 10 7 7 0.8



Machining tolerances for housings
Bearings (mm)housing diameter roundness(○) perpendicularity(⊥) parallelism(∥) roughness Ra
Nominal dimension upper lower t1(µm) t3(µm) t4(µm) Ra(µm)
YRT200 300 +0.025 -0.007 12 8 8 0.8

YRT200  yrt rotary table bearings factory 2

YRT200  yrt rotary table bearings factory 3
