Name: 7207ACP5/DBB Customized Single Row Angular Contact Ball Bearing High Load Capacity
Brand: MONTON
SKU: 7207ACP5/DBB
Rating: 4.8 (111 reviews)

Features Gallery Product Description Request A Quote

Features

Specifications

High Light:

angular contact thrust bearing

thin section angular contact bearings

Basic Infomation

Place of Origin: CHINA

Brand Name: MONTON

Certification: ISO9001

Model Number: 7207ACP5/DBB

Payment & Shipping Terms

Packaging Details: Singlebox

Delivery Time: 7-35 days

Payment Terms: T/T

Supply Ability: 10000PCS/WEEK

Gallery

7207ACP5/DBB Customized Single Row Angular Contact Ball Bearing High Load Capacity

Product Description

The Single Row Angular Contact Ball Bearings are non-separable and the bearing rings have one high and one low shoulder. The low shoulder enables a large number of balls to be incorporated in the bearing, giving it a relatively high load carrying capacity.

Some large size bearings are available with a flanged outer ring.

In addition, Huihao's single row angular contact ball bearings are available in many other designs, dimension series, and sizes.

7207ACP5/DBB Customized Single Row Angular Contact Ball Bearing High Load Capacity 0

BASIC	BORE(d)	O.D(D).	WIDTH		WEIGHT
BEARING			B	2B
NUMBER	mm	mm	mm	mm	kg/lb
	inch	inch	inch	inch
7200	10	30	9	18	0.029/0.064
	0.3937	1.1811	0.3543	0.7087
7201	12	32	10	20	0.035/0.077
	0.4724	1.2598	0.3937	0.7874
7202	15	35	11	22	0.046/0.101
	0.5906	1.378	0.4331	0.8661
7203	17	40	12	24	0.064/0.141
	0.6693	1.5748	0.4724	0.9449
7204	20	47	14	28	0.100/0.220
	0.7874	1.8504	0.5512	1.1024
7205	25	52	15	30	0.125/0.275
	0.9843	2.0472	0.5906	1.1811
7206	30	62	16	32	0.193/0.425
	1.1811	2.4409	0.6299	1.2598
7207	35	72	17	34	0.281/0.618
	1.378	2.8346	0.6693	1.3386
7208	40	80	18	36	0.355/0.781
	1.5748	3.1496	0.7087	1.4173
7209	45	85	19	38	0.404/0.889
	1.7717	3.3465	0.748	1.4961
7210	55	90	20	40	0.457/1.005
	2.1654	3.5433	0.7874	1.5748
7211	55	100	21	42	0.600/1.320
	2.1654	3.937	0.8268	1.6535
7212	60	110	22	44	0.765/1.683
	2.3622	4.3307	0.8661	1.7323
7213	65	120	23	46	0.962/2.116
	2.5591	4.7244	0.9055	1.811
7214	70	125	24	48	1.09/2.398
	2.7559	4.9213	0.9449	1.8898
7215	75	130	25	50	1.17/2.574
	2.9528	5.1181	0.9843	1.9685
7216	80	140	26	52	1.39/3.058
	3.1496	5.5118	1.0236	2.0472
7217	85	150	28	56	1.78/3.916
	3.3465	5.9055	1.1024	2.2047
7218	90	160	30	60	2.18/4.796
	3.5433	6.2992	1.1811	2.3622
7219	95	170	32	64	2.67/5.874
	3.7402	6.6929	1.2598	2.5197
7220	100	180	34	68	3.2/7.040
	3.937	7.0866	1.3386	2.6772
7221	105	190	36	72	3.79/8.338
	4.1339	7.4803	1.4173	2.8346
7222	110	200	38	76	4.45/9.790
	4.3307	7.874	1.4961	2.9921
7224	120	215	40	80	6.26/13.772
	4.7244	8.4646	1.5748	3.1496
7226	130	230	40	80	7.15/15.730
	5.1181	9.0551	1.5748	3.1496
7228	140	250	42	84	8.78/19.316
	5.5118	9.8425	1.6535	3.3071
7230	150	270	45	90	11.00/24.200
	5.9055	10.6299	1.7717	3.5433
7232	160	290	48	96	13.7/30.140
	6.2992	11.4173	1.8898	3.7795
7234	170	310	52	104	17.00/37.400
	6.6929	12.2047	2.0472	4.0945
7236	180	320	52	104	17.70/38.940
	7.0866	12.5984	2.0472	4.0945
7238	190	340	55	110	21.30/46.860
	7.4803	13.3858	2.1654	4.3307
7240	200	360	58	106	25.30/55.660
	7.874	14.1732	2.2835	4.1732
