71826 CDGA/P4A Angular Contact Ball Bearing Spindle Bearing
71826 CDGA/P4A Bearing Specification :
Model Number | 71826 CDGA/P4A |
Part Name | Angular Contact Ball Bearing |
Row | Single Row |
Dimensions(mm)(d*D*b) | 130mm X 165mm X 18mm |
Weight / Mass ( KG ) | 0.782kg |
Precision Rating | ABEC-7/ P4 |
Brand | Moton |
Original Country Show | CHINA |
Bearing No. | Size | Basic Load | Limited Speed | Mass | ||||
d | D | B | Cr | Cor | Grease | ≈ | ||
mm | KN | r/min | kg | |||||
71803CD/P4A Bearing | 17 | 26 | 5 | 2.3 | 1.9 | 53000 | 80000 | 0.008 |
71803CDGA/P4A Bearing | ||||||||
71803CDGB/P4A Bearing | ||||||||
71803CDGC/P4A Bearing | ||||||||
71803ACD/P4 Bearing | 17 | 26 | 5 | 2.1 | 1.8 | 50000 | 75000 | 0.008 |
71803ACDGA/P4A Bearing | ||||||||
71803ACDGB/P4A Bearing | ||||||||
71803ACDGC/P4A Bearing | ||||||||
71804CD/P4A Bearing | 20 | 32 | 7 | 3.9 | 3.4 | 45000 | 67000 | 0.018 |
71804CDGA/P4A Bearing | ||||||||
71804CDGB/P4A Bearing | ||||||||
71804CDGCP4A Bearing | ||||||||
71804ACD/P4A Bearing | 20 | 32 | 7 | 3.7 | 3.2 | 40000 | 60000 | 0.018 |
71804ACDGA/P4A Bearing | ||||||||
71804ACDGB/P4A Bearing | ||||||||
71804ACDGC/P4A Bearing | ||||||||
71805CD/P4A Bearing | 25 | 37 | 7 | 4.2 | 4.1 | 38000 | 56000 | 0.022 |
71805CD/P4A Bearing | ||||||||
71805CD/P4A Bearing | ||||||||
71805CD/P4A Bearing | ||||||||
71805ACD/P4A Bearing | 25 | 37 | 7 | 3.9 | 3.9 | 34000 | 50000 | 0.022 |
71805ACDGA/P4A Bearing | ||||||||
71805ACDGB/P4A Bearing | ||||||||
71805ACDGC/P4A Bearing | ||||||||
71806CD/P4A Bearing | 30 | 42 | 7 | 4.4 | 4.8 | 32000 | 48000 | 0.025 |
71806CDGA/P4A Bearing | ||||||||
71806CDGB/P4A Bearing | ||||||||
71806CDGC/P4A Bearing | ||||||||
71806ACD/P4A Bearing | 30 | 42 | 7 | 4.1 | 4.5 | 28000 | 43000 | 0.025 |
71806ACDGA/P4A Bearing | ||||||||
71806ACDGB/P4A Bearing | ||||||||
71806ACDGC/P4A Bearing | ||||||||
71807CD/P4A Bearing | 35 | 47 | 7 | 4.6 | 5.5 | 26000 | 40000 | 0.029 |
71807CDGA/P4A Bearing | ||||||||
71807CDGB/P4A Bearing | ||||||||
71807CDGC/P4A Bearing | ||||||||
71807ACD/P4A Bearing | 35 | 47 | 7 | 4.3 | 5.2 | 24000 | 38000 | 0.029 |
71807ACDGA/P4A Bearing | ||||||||
71807ACDGB/P4A Bearing | ||||||||
71807ACDGC/P4A Bearing | ||||||||
71808CD/P4A Bearing | 40 | 52 | 7 | 4.8 | 6.2 | 24000 | 38000 | 0.032 |
71808CDGA/P4A Bearing | ||||||||
71808CDGB/P4A Bearing | ||||||||
71808CDGC/P4A Bearing | ||||||||
71808ACD/P4A Bearing | 40 | 52 | 7 | 4.5 | 5.8 | 20000 | 34000 | 0.032 |
71808ACDGA/P4A Bearing | ||||||||
71808ACDGB/P4A Bearing | ||||||||
71808ACDGC/P4A Bearing | ||||||||
71809CD/P4A Bearing | 45 | 58 | 7 | 4.9 | 6.7 | 20000 | 34000 | 0.04 |
