7236ACP4/DBB High Precision Angular Contact Ball Bearing for Construction Equipment
P4 High Precision Angular Contact Ball Bearing 7236ACP4/DBB
7236 bearings, angular contact ball bearing, is made of Chrome Steel. which have a contact angle so that they can sustain significant axial loads in one direction together with radial loads.
7236 bearings have raceways in the inner and outer rings that are displaced with respect to each other in the direction of the bearing axis. This means that they are designed to accommodate combined loads, i.e. simultaneously acting radial and axial loads.The axial load carrying capacity of angular contact ball bearings increases with increasing contact angle. The contact angle α is defined as the angle between the line joining the points of contact of the ball and the raceways in the radial plane, along which the load is transmitted from one raceway to another, and a line perpendicular to the bearing axis.
Quick details of P4 High Precision Angular Contact Ball Bearing 7236A
Model: 7236ACP4DBB | Brand Name: Monton |
Inside Diameter: 180mm | Outside Diameter: 320mm |
Greased speed: 1600r/min | Oil speed: 2200r/min |
Breadth : 52mm | Weight: 18KG |
Material: GCr15SiMn, GCr15, etc | Usage: Widely used in industries |
Seals Type: Bearing seal | Retainer/Cage: CA/CC/steel /MB/TVPB |
Advantages of 7236 bearings
1.Low friction, almost noiseless and high rolling speed
2.Easy to install
3.Simple structure ensures fast equipment
4.Optimised internal design
5.High load ratings
6.Increased limiting speed
7.High strength ball guided brass cage
8.High dimensional and running accuracy
9.Narrow axial clearances or preloads range
10.Universal facing in standard
Model Number
Bearing NO. | Size | 15º | 25º | ||||
Limiting Speed | Limiting Speed | ||||||
ID | OD | B | Loading rating | Grease & Oil | Loading rating | Grease & Oil | |
Cr Cor | Grease Oil | Cr Cor | Grease Oil | ||||
7003 | 17 | 35 | 10 | 6.7 4.9 | 44000 66000 | 6.4 4.7 | 39000 59000 |
7004 | 20 | 42 | 12 | 9.6 6.3 | 37000 55000 | 9.2 6.0 | 33000 49000 |
7005 | 25 | 47 | 12 | 12.9 8.7 | 33000 49000 | 12.3 8.3 | 29000 44000 |
7006 | 30 | 55 | 13 | 15.7 11.6 | 27000 42000 | 14.9 10.9 | 23000 37000 |
7007 | 35 | 62 | 14 | 19.3 17.5 | 19000 33000 | 10.4 10.3 | 19000 33000 |
7008 | 40 | 68 | 15 | 19.9 19.1 | 18000 31000 | 18.9 18.2 | 16000 27000 |
7009 | 45 | 75 | 16 | 26.7 25.3 | 16000 27000 | 25.4 24.1 | 15000 25000 |
7010 | 50 | 80 | 16 | 27.6 27.5 | 15000 25000 | 26.2 26.2 | 14000 23000 |
7011 | 55 | 90 | 18 | 36.7 37.1 | 13000 21000 | 34.8 35.3 | 12000 19000 |
7012 | 60 | 95 | 18 | 37.8 40 | 13000 21000 | 35.8 38 | 11000 18000 |
7013 | 65 | 100 | 18 | 38.9 42.9 | 12000 19000 | 36.8 40.7 | 10000 17000 |
7014 | 70 | 110 | 20 | 49.9 55.5 | 11000 18000 | 47.2 52.7 | 9000 16000 |
7015 | 75 | 115 | 20 | 51.3 59.2 | 10000 17000 | 48.5 56.2 | 8500 15000 |
7016 | 80 | 125 | 22 | 61.6 70.4 | 9000 16000 | 58.3 66.9 | 8000 14000 |
7017 | 85 | 130 | 22 | 63.6 75 | 8500 15000 | 59.9 71.3 | 7500 13000 |
7018 | 90 | 140 | 24 | 66.9 84 | 8000 14000 | 63.2 79.7 | 7000 12000 |
7019 | 95 | 145 | 24 | 79.1 97.6 | 7500 13000 | 74.8 92.7 | 6500 11000 |
7020 | 100 | 150 | 24 | 81.2 103.3 | 7000 12000 | 76.7 9.8 | 6000 10000 |
7021 | 105 | 160 | 26 | 93.9 118.2 | 6500 11000 | 88.8 112.2 | 6000 10000 |
7022 | 110 | 170 | 28 | 110.4 139.8 | 6000 10000 | 104.4 132.8 | 5700 9000 |
7024 | 120 | 180 | 28 | 112.7 148.7 | 6000 10000 | 106.3 141.1 | 5700 9000 |
7026 | 130 | 200 | 33 | 144.8 190.8 | 5700 9000 | 136.8 181.0 | 5000 8000 |
7028 | 140 | 210 | 33 | 148.7 202.6 | 5000 8000 | 140.4 192.2 | 4600 7500 |
7030 | 150 | 225 | 35 | 168.4 232.5 | 4600 7500 | 159.1 220.6 | 4000 6500 |
