Spindle bearings HCB71834-C-TPA-P4
|
|
|
adjusted, in pairs or sets, contact angle α = 15°, restricted tolerances,
Bearing with ceramic ball,high speed,P4 Precision grade, in stock
|
| Products name |
HCB71834-C-TPA-P4 |
| Current bearing code |
HCB71834-C-TPA-P4 |
| Made in |
China |
| dimensions |
170x215x22mm |
| Inner diameter |
170mm |
| Outer diameter |
215mm |
| Height |
22mm |
| Precision Rating |
P4 |
| Quality standard |
DIN620 |
| basicload rating(KN) |
Cr:47.5 KN |
| Cor:61 KN |
| Limiting Speed (r/min) |
Grease:6300 r/min |
| Oil:9500 r/min |
| Weight |
1.6 kgs |
B:Standard steel balls.
HCB:Hybrid standard ceramic balls.
XCB:Cronidur standard ceramic balls.
RS:High speed bearing steel balls
HCRS:High speed bearing ceramic balls
HS:Bearing with small balls steel balls
HSS:Bearing with small balls ceramic balls
HC:Bearing with small balls ceramic balls
HCS:Bearing with small balls ceramic balls
XC: Cronidur bearing with small balls ceramic ball
XCS:Cronidur bearing with small ceramic balls sealed
Dimension series: 719 Light series, 70 Medium series,72 Heavy series
Preload:
L:Light, M: Moderate, H:Heavy.
Bearing arrangement:
U: Individual bearing, suitable for any arrangement,
DU :Duplex set, universal bearings
TU:Triplex set,universal bearing
QY:Quadruplex set,universal bearing
PU:Quintuplex set,universal bearing
P4S:FAG Standard better than P4 to DIN620
P4S-KS:Restricted diameter tolerance compare to P4S
T: Laminated fabric guidance on outer ring
2RSD Sealed on both sides and greased
CDLR:Direct lubrication 15°
DDLR: annular grooves 20°
EDLR: With O rings 25°
C:15° D 20° E 25°
