ZKLN3062-2RS 30*62*28mm Angular Contact Ball Bearing high precision
angular contact ball bearing
Designation | Dimensions | Mounting dimensions | Basic load ratings axial |
Recommended precision locknut | Required locknut force3) axial N |
Mass m = kg |
|||||||||
d | D –0,010 |
B –0,25 |
d1 | r min. |
r1 min. |
Da max. |
da min. |
dyn. Ca N |
stat. C0a N |
For radial locking | For axial locking | Tightening torque4) MA Nm |
|||
ZKLN3062-2RS | 30 | 62 | 28 | 45.5 | 0.3 | 0.6 | 53 | 40 | 32000 | 64000 | ZM30 | AM30 | 32 | 9947 | 0.39 |
ZKLF1255-2RS-XL Axial Angular Contact Bearing
These bearings are designed for the highly dynamic operating conditions in screw drives that require high accuracy, high load carrying capacity, high rigidity, low friction and maintenance-free or low-maintenance.
The bearings can support both radial forces and high axial forces due to the 60� contact angle.
The ZKLF bearing range are designed to be screw mounted directly on the adjacent construction or in a radial locating bore.
Double direction
Lip seals on both sides
