ZKLN70120-2Z 70*120*45mm high speed high precision ceramic spindle ball bearing
Features Gallery Product Description Request A Quote
Features
Specifications
Material: GCr15
Accuracy: P4 Or P2
Structure: Axial Angular Contact Ball Bearings
Type: Ball Screw Double Row
Customers: DMG,FFG,etc
Market: Germany,Japan,Italy,USA,etc
Matched Ways: Universal Or Pairs
Basic Infomation
Place of Origin: CHINA
Brand Name: MONTON
Certification: ISO9001
Model Number: ZKLN70120-2Z
Payment & Shipping Terms
Packaging Details: Singlebox
Delivery Time: 7-35 days
Payment Terms: T/T
Supply Ability: 10000PCS/WEEK
Product Description

ZKLN70120-2Z 70*120*45mm high speed high precision

ceramic spindle ball bearing​

Designation Dimensions Mounting dimensions Basic load ratings
axial
Recommended precision locknut Required locknut force3)
axial
N
Mass
m
= kg
d D
–0,010
B
–0,25
d1 r
min.
r1
min.
Da
max.
da
min.
dyn. Ca
N
stat.
C0a N
For radial locking For axial locking Tightening torque4)
MA
Nm
ZKLN70120-2Z 70 120 45 95 0.6 0.6 110 92 97000 241000 ZMA70/110 AM70 130 19031 2.4



Product Description



These bearings are designed for the highly dynamic operating conditions in screw drives that require high accuracy, high load carrying capacity, high rigidity, low friction and maintenance-free or low-maintenance.

The bearings can support both radial forces and high axial forces due to the 60� contact angle.

The ZKLN bearing range is mounted� in a housing bore and the bearing outer ring is axially located by a cover.

Double direction
PE: Increased tolerances, used when lower accuracy is acceptable
Lip seals on both sides

ZKLN..PE Series Angular Contact Bearings: Bearings of series ZKLN..PE are double row axial angular contact ball bearings with an outer ring suitable for mounting in a housing and has integral seals. These bearings are predominantly used for the bearing arrangements of screw drives and are an extremely economical solution for criteria such as a simple adjacent construction and low fitting costs. The larger sizes of these bearings – with a bore diameter of 60 mm to 100 mm are particularly suitable for bearing arrangements of large threaded spindles or rotating threaded nuts, in other words screw drives with a static spindle.
Double row axial angular contact ball bearings of series ZKLN...2RSPE have two rows of balls with a contact angle of 60deg. The bearings are sealed on both sides with rubber seals and are greased for life for the majority of applications. Additional seals in the adjacent construction are not required. In most applications, the initial greasing is sufficient for the whole operating life. If necessary, re lubrication can be carried out via a threaded connector from a central lubrication system on the flange side or by means of a lubrication groove and lubrication hole via the adjacent construction. The axial run out tolerance corresponds approximately to P5 in accordance with DIN 620.
