Name | Angular contact ball bearing |
Seires | BAR Series |
Brand | MONTON |
Model | 120BTR10STYNDBLP4A |
Contact Angle | 15°/25°/40° |
d | 120mm |
D | 180mm |
2B | 54.0mm |
Ring Material | Gcr15/ Carbon Steel/ Stainless Steel/ Si3N4/ ZrO2 |
Cage Material | Nylon/phenolic resin |
Load rating C | 68.0N |
Load rating Co | 160kN |
Grease speed | 4 400 |
Oil speed | 5 700 |
Sealed | as customer requested |
Weight | 2.262KG |
Bearing Arrangement | U/DB/DT/TBT/QBC/DU/QU ect. |
Design Structure | Angular contact |
Precision | P4,P5 or as customer requested |
Vibration | ZV1, ZV2, ZV3, or as customer requested |
Clearance | C0, C2, C3, or as customer requested |
Quality standard | ISO9001: 2000/SGS |
Package | single box |
Original | Luoyang |
Service | OEM |
Delivery date | Accordingly |
Application | Spindle,Auto, tractor ,machine tool, electric machine, water pump, agricultural machinery and textile machinery,air compressor,shippiing.logistic,areospace |
