H7002C -2RZHQ1P4DBA Ceramic Angular Contact Ball Bearing

Minimum Order Quantity : 1pcs Price : USD
Packaging Details : Single box/Wooden case Delivery Time : 7-35 days
Supply Ability : 1000PCS/DAY
Place of Origin: Luoyang Brand Name: Monton
Model Number: H7002C-2RZHQ1P4DBA

Detail Information

High Light:

angular contact thrust bearing

,

thin section angular contact bearings

Product Description

H7002C-2RZHQ1P4DBA 15*32*9mm

angular contact bearings ceramic angular contact ball bearings



Part Number H7002C-2RZHQ1P4DBA
Bearing Type Angular contact ball bearing
For Load Direction Combined Radial and Thrust
Construction One
Single Row/Double Row Single
Seal Type Open
Precision Rating P4 (ABEC-7) P5 (ABEC-5)
Contact Angle 15
Duplex DB (back-to-back arrangement)
DF (face-to-face arrangement)
DT (tandem arrangement)
Bore Dia (d) 15 mm
Bore Dia Tolerance -0.004mm to 0
Outer Dia (D) 32 mm
Outer Dia Tolerance -0.006mm to 0
Width (B) 9 mm
Width Tolerance -0.08mm to 0
Ring Material Gcr15
Ball Material SN24 Ceraimc Ball Si3N4
Cage Material TYN (ball guided polyamide resin cage)
TR (outer ring guided polyamide resin cage)
Dynamic Load Rating (Cr) (KN) 6.55
Static Load Rating (Cor) (KN) 3.4
Axial Load (KN) 2.63
Max Speed (Grease) (RPM) 49000
Max Speed (Oil) (RPM) 74500
Preload EL (extra light preload)
L (light preload)
M (medium preload)
H (heavy preload)
CP (special preload)
CA (special axial clearance)
Lubrication Required
Shaft Mount Type Press Fit
Temperature Range -40 to 120 ºC
Weight (grams) 0.03
H7002C-2RZHQ1P4DBB,H7002C-2RZHQ1P5DBA,H7002C-2RZHQ1P5DBB,H7002C-2RZHQ1P4SUL,H7002C-2RZHQ1P5SUL
