Precise Worm Gear Slew Drive , Hydraulic Slew Drive Fit Solar Tracking System

1
MOQ
USD
Price
Precise Worm Gear Slew Drive , Hydraulic Slew Drive Fit Solar Tracking System
Features Gallery Product Description Request A Quote
Features
Specifications
Material: 50Mn Or 42CrMo
Delivery: 20 Working Days
Application: Solar Tracker And Wind Turbine Or Contruction Machines Or Equipment
Range: 50~500mm
Production Ability: 20000pcs/month
Market: Spain,USA,Russia,etc
Keywords: Solar Tracker Slew Drive For Heavy Duty Vehicle Solar Tracker Se-2 Series Slewing Drive For Solar System
High Light:

slew rate control driver

,

slewing ring drive

Basic Infomation
Place of Origin: LUOYANG
Brand Name: MONTON
Certification: ISO9001 or CE certificate
Model Number: WEA17
Payment & Shipping Terms
Packaging Details: Single box/Wooden case
Delivery Time: 7-35 days
Payment Terms: TT
Supply Ability: 1000/pcs/week
Product Description

china solar tracking bracket slewing drive supplier customized solar tracking bracket slewing drive



The slewing drive is a modernized take on the worm drive mechanism that dates back many centuries and was widely used during the Renaissance Era. Pappus of Alexandria (3rd century AD), a Greek mathematician is credited for an early version of the endless screw, which would later evolve into the worm drive. This mechanism was also used by Leonardo da Vinci as a component in many of his designs for machines. It can also be found in the notebooks of Francesco di Giorgio of Siena.


WEA series slewing drive,slew drive is a new series of slewing product, also named as slewing reducer. It is commonly composed of worm,slewing bearing, housing, motor adapter, end cap and other components. By adopting slewing bearing as its core component, slewing drive can bear axial force, radial force and tilting moment simultaneously. Comparing with SE series slewing drive, WEA series have the advantages

of better protective performance, great transmission torque, better impact resistance and long working life.

WEA series slewing drive is widely applied in the relatively rotary parts of machinery and solar energy field. Solar tracking system Rotary chassis

of aerial working machinery Truck crane Rock drill, drilling machine Grasping wood machine, code molding machine.



Applications for the slewing bearings include:

Slewing Drive for solar tracking system
Slewing Drive for PV Application
Slewing Drive for Construction Machinery Application
Aerial working platform
Manlifts, Skylifts
Telescopic boom skylifts
Articulating boom skylifts
Truck mounted crane
lorry loaders
Loader cranes
Marine cranes
Hydraulic grapples
forklift attachments
woods log grapple
single axis solar tracker
dual axis solar tracker
solar tracking system

customized slew drive sun tracker
customized slew ring sun tracking
customized slewing drive sun tracker
customized solar tracking bracket slewing drive
customized tracking bracket slewing drive
customized worm gear sun tracker
dish solar tracker slew drive factory
double enveloping worm gear
dual axis slew drive
dual axis slew drive factory
dual axis slew drive for aerial working platform
dual axis slew drive for construction machinery
dual axis slewing drive
dual axis slewing drive for aerial working platform
dual axis slewing drive for solar system for aerial working platform
dual axis slewing drive for solar system for construction machinery







Model WORM DRIVE WEA17
Worm Drive Performance Parameters
ID 332
OD 510
H 108
Output Torque 10.8 kN.m
Tilting MomentTorque 67.8 kN.m
Holding Torque 48 kN.m
Static Axial Rating 920 kN
Static Radial Rating 343 kN
Dynamic Axial Rating 220 kN
Dynamic Radial Rating 190 kN
Gear Ratio 86: 1
Tracking Precision ≤ 0.13°
Input Ø12 Ø14 Ø16 Ø20 Ø25
SPLINE
Weight 96kg

CUSTOMIZED ACCORDING TO REQUESTS
APPLICATION Slewing Drive for solar tracking system
  Slewing Drive for PV Application
  Slewing Drive for Construction Machinery Application
  Aerial working platform
  Manlifts, Skylifts
  Telescopic boom skylifts
  Articulating boom skylifts
  Truck mounted crane
  lorry loaders
  Loader cranes
  Marine cranes
  Hydraulic grapples
  forklift attachments
  woods log grapple
  single axis solar tracker
  dual axis solar tracker
  solar tracking system
