Series |
M541300 |
Cone Part Number |
M541349 |
Cup Part Number |
M541310CD |
Design Units |
Imperial |
Bearing Weight |
46.68 lb21.173 Kg |
Cage Type |
Pin-Type |
Ab - Cage-Cone Frontface Clearance |
0.22 in5.6 mm |
d - Bore |
8 in203.2 mm |
D - Cup Outer Diameter |
11.5000 in292.100 mm |
B - Cone Width |
1.9375 in49.213 mm |
C - Double Cup Width |
3.3125 in84.138 mm |
T - Bearing Width across Cones |
4.3124 in109.535 mm |
| R - Cone Backface "To Clear" Radius1 | 0.14 in3.600 mm |
| r - Cup Frontface "To Clear" Radius2 | 0.03 in0.8 mm |
db - Cone Backface Backing Diameter |
8.7 in221 mm |
Da - Cup Frontface Backing Diameter |
11.10 in280.92 mm |
Aa - Cage-Cone Backface Clearance |
0.11 in2.8 mm |
| C90 - Dynamic Radial Rating (One-Row, 90 million revolutions)3 | 39100 lbf174000 N |
| C1 - Dynamic Radial Rating (Two-Row, 1 million revolutions)4 | 263000 lbf1170000 N |
| C90(2) - Dynamic Radial Rating (Two-Row, 90 million revolutions)5 | 68200 lbf303000 N |
| Ca90 - Dynamic Thrust Rating (90 million revolutions)6 | 26800 lbf119000 N |
| K - Factor7 | 1.46 |
| e - ISO Factor8 | 0.86 |
| Y1 - ISO Factor9 | 0.781.17 |
| Y2 - ISO Factor10 | 1.17 |
| G1 - Heat Generation Factor (Roller-Raceway)11 | 752 |
G2 - Heat Generation Factor (Rib-Roller End) |
147 |
| Cg - Geometry Factor12 | 0.125 |
We export high quantities M541349/M541310CD/M541349XA Bearing and relative products, we have huge stocks for Bearing and relative items, we supply high quality M541349/M541310CD/M541349XA Bearing with reasonbable price andwe produce the bearings along with the technical data or relative drawings, It's priority to us to supply best service to our clients. If you are interested in M541349/M541310CD/M541349XA Bearing.
